DM SERIES
WATER-COOLED ENGINE
Features :
• Power- 8.5, 10 & 14 HP
• Single Cylinder & Twin Cylinder Air Cooled Diesel Engine
• Clockwise/Anti-Clockwise
• Suitable for Multi-Application
| Technical Specifications | ||||
| Model | Units | DM8.5 | DM10 | DM14 |
| No of Cylinders | 1 | 1 | 1 | |
| Bore X Stroke | mm | 95 X 110 | 102 X 116 | 114 X 116 |
| Cubic Capacity | Ltr | 0.78 | 0.94 | 1.19 |
| Compression Ratio | 17.5:1 | 17.5:1 | 15.5:1 | |
| Rated Output | kW/HP | 6.25/8.5 | 7.4/10 | 10.3/14 |
| Rated Speed | rpm | 1500 | 1500 | 1500 |
| Crankshaft Center Height | mm | |||
| Specific Fuel Consumption | (Gm/Hp-Hr) | 185+/-5% | 185+/-5% | 185+/5% |
| Lube Oil Sump Capacity | Ltr | 3.7 | 3.7 | 3.7 |
| Lube Oil Consumption | % | 1%ofSFCMax. | 0.8%ofSFCMax. | |
| Fuel Tank Capacity | Ltr | 11.5 | 11.5 | 20 |
| Dimension LXWXH | mm | 617X532X850 | 685X532X850 | 550X550X855 |
| Engine Weight | Kg | 177 | 1770 | 204 |
| Flywheel Rotation | Clockwise | |||
| Power Take-off | Flywheel end | |||
| Starting | Hand Start | |||
| Governing | CLASS “B1/A2” | |||
| Type of Fuel Injection | Direct Injection | |||
| Overloading Capacity of Engine | 10% of the Rated Output | |||
